Speedwash SW40 Commercial Dishwasher - Nelson Dish & Glasswashing Machines

SW40 Commercial Dishwasher

£1,800.00 £2,655.00
− +

  • Reliable and easy to use, built to withstand the harshest working environments.

  • SW40 commercial dishwasher can wash up to 480 plates per hour.

  • Loading height of 330mm can accommodate virtually any dishware and crockery.

  • The best small commercial dishwasher for cafes, coffee shops, and small to medium bars, pubs and restaurants.

 Dishwasher Basket Size: 400mm x 400mm

Key Features
  • SW40 Commercial Dishwasher Loading Height: 265mm
  • SW40 Commercial Dishwasher Basket Size: 400mm x 400mm
  • 120 second fixed wash cycle
  • Commercial dishwasher with built in water softener option
  • Commercial dishwasher with built in drain pump
  • Factory-fitted integral break tank “Type A” air gap (optional)
  • Top and bottom wash and rinse arms ensure total coverage of the wash area
  • Economical wash reservoir with easy-to-clean, sloping wash tank
  • Thermostatically controlled wash and rinse temperatures
  • Enhanced filtration system with two layers of protection
  • Automatic shut-off wash cycle on door opening
  • Fully automatic detergent and rinse-aid dosing injectors
  • Machine cabinet constructed entirely from the highest grade stainless steel
  • Fully CE and WRC approved and certified
  • Electrical requirements: 15amp single phase
  • SW40 Commercial Dishwasher Dimensions: 480mm (W) x 520mm (D) x 700mm (H)
     Machine Variants
     Model Number Description   Power Dimensions (W x D x H)  Cycle Times (seconds)
    SW40UDDPBT commercial dishwasher with inbuilt Drain Pump & Break Tank 230V 1N 50Hz / 2.6kW  480mm x 520mm x 700mm 90, 180, 240
    SW40UDWSDPBT Commercial Dishwasher with Inbuilt Water Softener, Drain Pump & Break Tank 230V 1N 50Hz / 2.6kW 480mm x 520mm x 700mm 90, 180, 240



    Technical Information
    • Structure: Single skinned, in AISI 304 stainless steel
    • Control type: Electronic
    • Basket dimensions: 400mm x 400mm
    • Baskets per hour: 40 / 24/ 15
    • Number of programmes: 3
    • Rinse-aid dispenser: Peristaltic pump with electronic adjustment
    • Detergent dispenser: Peristaltic pump with electronic adjustment
    • Useable loading height: 310mm can accommodate virtually any dish ware.
    • Wash tank capacity: 8L
    • Boiler capacity: 4L
    • Boiler heating element: 2.3kW
    • Wash tank heating element: 2.0kW
    • Outside dimensions (WxDxH): 440 x 530 x 710
    • Power supply / Total power installed: 230V 1N 50hZ / 2.6kW
    • Weight (net/gross): 40/46 Kg
    • Commercial  Dishwasher with Integral water softener: optional
    • Wash system: Wash pump with 'soft start' system
    • Wash pump: 0.3kW
    • Rinse system: Atmospheric boiler and rinse pump (HTR system)
    • Drain system: Automatic drain pump with partial water exchange in the wash tank
    • Wash and Rinse arm: 2x combined wash and rinse arm with quick release system
    • Insulated double-skinned door
    • EXTENDED-RINSE function for prolonged rinse
    • Thermostop for controlling the rinse water temperature
    • Self-diagnosis system with fault warning
    • Moulded basket guides
    • Drain pipe on the boiler for complete drainage
    • 'Stand-by' function of the heating elements during periods of non-use
    • Moulded tank with rounded corners
    • Self-cleaning cycle available as standard
    • Automatic partial replacement of water in the wash tank by drain pump between wash and rinse cycles
